Introduction to the DRSD-05 Hydraulic Pipe Bender
The DRSD-05 Hydraulic Pipe Bender is a device that uses a hydraulic system to provide power and bend metal pipes through molds and fixtures. It is widely used in industries such as construction, automotive, aerospace, mechanical manufacturing, and shipbuilding to produce pipe components of various shapes.
1. Working Principle
The core of the DRSD-05 Hydraulic Pipe Bender is the hydraulic system, which drives the mold to apply pressure to the pipe through the reciprocating motion of the hydraulic cylinder. This causes the pipe to undergo plastic deformation under the action of the bending mold, thereby achieving the bending of the pipe. The basic steps of its working principle are as follows:
-
Pipe Clamping: The pipe to be processed is fixed in the fixture.
-
Mold Positioning: The bending mold is moved to the bending position of the pipe.
-
Hydraulic Drive: The hydraulic cylinder pushes the mold to apply bending force to the pipe.
-
Bending Formation: The pipe gradually bends under the action of the mold until the desired angle is reached.
-
Return and Reset: After bending is completed, the hydraulic cylinder retracts, the mold resets, and the formed pipe is removed.
2. Main Features
The DRSD-05 Hydraulic Pipe Bender has the following significant features:
-
High Precision: It can accurately control the bending angle and radius to ensure processing quality.
-
High Efficiency: The hydraulic system provides strong power to quickly complete the bending operation.
-
Easy Operation: Equipped with an advanced control system, it is simple to operate and easy to learn.
-
Strong Adaptability: It can process pipes made of various materials, such as carbon steel, stainless steel, and aluminum alloy.
-
High Safety: The hydraulic system has overload protection to ensure the safety of the equipment and operators.
3. Application Fields
The hydraulic pipe bender is widely used in the following fields:
-
Construction Industry: For producing pipes, railings, and stair handrails.
-
Automotive Manufacturing: For manufacturing automotive exhaust pipes, cooling pipes, and other components.
-
Aerospace: For processing aircraft engine pipes and hydraulic system pipes.
-
Mechanical Manufacturing: For producing pipe bending parts of various mechanical components.
-
Shipbuilding: For manufacturing the piping systems and structural components of ships.
4. Advantages of the DRSD-05
-
High Degree of Automation: Modern hydraulic pipe benders are usually equipped with CNC systems to achieve automated operation.
-
High Repeatability: It can ensure the consistency of the shape and size of the pipes processed each time.
-
Wide Material Adaptability: It can process pipes of various diameters and wall thicknesses.
-
Low Maintenance Cost: The hydraulic system is compact and easy to maintain.
